MAX19000 Evaluation Kit
Table_1._Digital_Interface_Jumper_Settings_(continued)
JUMPER
JU18
JU23
JU24
SHUNT_
POSITION
1-2*
Open
1-2*
Open
1-2*
Open
DESCRIPTION
Connects the DGS pin of the MAX19000 to the ground
Disconnects the DGS pin of the MAX19000 from the ground
Connects the GNDDAC0 pin of the MAX19000 to the ground
Disconnects the GNDDAC0 pin of the MAX19000 from the ground
Connects the GNDDAC1 pin of the MAX19000 to the ground
Disconnects the GNDDAC1 pin of the MAX19000 from the ground
* Default position.
Table_2._Power_Supplies_Jumper_Settings
JUMPER
JU1
JU2
JU3
JU15
JU16
JU19
JU20
JU21
JU22
SHUNT_
POSITION
1-2
Open*
1-2
Open*
1-2*
Open
1-2
Open*
1-2*
Open
1-2*
Open
1-2*
Open
1-2*
Open
1-2*
Open
DESCRIPTION
Connects the ADJ pin of the regulator (U15) to ground through a 280 I resistor (R3) in parallel
with a 402 I resistor (R5)
Disconnects the ADJ pin of the regulator from R3
Connects the ADJ pin of the regulator (U15) to ground through a 2.26k I resistor (R4)
Disconnects the ADJ pin of the regulator from R4
Connects the VT_C to the on-board regulator (U17)
Disconnects the 1.25V (VT_C) from the on-board regulator (U17)
Connects the ADJ pin of the regulator (U16) to ground through a 75 I resistor (R6) in parallel
with a 402 I resistor (R8)
Disconnects the ADJ pin of the regulator from R6
Connects the ADJ pin of the regulator (U16) to ground through a 249 I resistor (R7) in parallel
with a 402 I resistor (R8)
Disconnects the ADJ pin of the regulator from R7
Connects VCC to the on-board regulator (U14)
Disconnects VCC from the on-board regulator (U14)
Connects VDD to the on-board regulator (U15)
Disconnects VDD from the on-board regulator (U15)
Connects VT_DT to the on-board regulator (U16)
Disconnects VT_DT from the on-board regulator (U16)
Connects VEE to the negative power supply input jack
Disconnects VEE from the negative input power supply
* Default position.
________________________________________________________________________________________ _ 5
